Automatic start

Automatic panel for controlling ATS series RG 10 / 30 generators

The automatic backup power solution from Krel Central a.s.

A professional solution for the automatic start of an industrial generator
The device is safe and certified
The advantages of a high-quality industrial solution

Unlike various online offers of automatic generator starts, we offer a demonstrably CERTIFIED PRODUCT with certification based on tests at the state testing laboratory EZÚ Prague 8. This certificate guarantees the SAFETY OF THE PRODUCT, which complies with the applicable ČSN ⁠–⁠ EU standards. A copy of the certificate is part of the documentation supplied with the automatic backup power assembly.

Standard equipment of the RG 30 panel

Standard setting parameters

Mobile version of operating the ATS panel

Voltage monitoring on all 3 phases of the grid supply
The basic parameter settings can be adjusted to the customer's requirements.
The transfer contactors are designed for an AC 3 load
Backed-up TN⁠-⁠S output
Communication in English
Load tests of the starter battery
Timely disconnection of the load from the generator when fuel is low (generators must not be switched off under load, as this risks damaging the generator)
Easy connection of a GSM gateway for status signalling and the option of remote control of the generator's operation
Option to time-block the generator start during a public grid outage
Grid contactor control does not depend on the generator's starter battery
Extended 5 year warranty on the RX 500 control module
5 year warranty on the HONDA generator
Output for a fire button ⁠–⁠ a requirement of the fire brigade safety technicians (so-called fire prevention officers)
A flexible GUMEX exhaust hose 3 m long is part of the supply.
We supply only a complete, tested set including the connecting cables between the generator and the RG panel via connectors + a PE conductor for connecting the generator with the RG 30.
At the customer's request we also mount the RG panel on the wall and connect it to the prepared wiring of the protected grid supply and the backed-up output, including commissioning and testing.
A multi-position intelligent choke servo drive ⁠–⁠ a unique solution ensuring high starting reliability even in extreme conditions (the application has been verified at a mountain resort, where the generator is placed in the shelter of a mountain lodge ⁠–⁠ reliable operation verified even at a temperature of ⁠–18°C)
As direct manufacturers, by mutual agreement we can also offer non-standard application solutions.
